Wake-On-LAN (WOL) is an innovative network standard that allows you to turn on a computer remotely by sending a special data packet known as a "Magic Packet." This technology allows your computer to be in sleep or hibernation mode and wake up automatically when it receives the special packet over the network. When the computer is in standby mode, its network card continues to operate at low power, actively listening for Magic Packets. Once such a packet is received with the correct MAC address of the computer, the network card activates the entire system, allowing you instant access to the computer's resources from anywhere.
What are the System Requirements and Required Settings for Wake-On-LAN?
To enjoy the benefits of Wake-On-LAN technology, you need to ensure that your system meets certain hardware and software requirements and make several critical settings. This process, while requiring attention to detail, will allow you to turn on your computer remotely easily and efficiently.
What are the Required Hardware Requirements?
First and foremost, you will need a network card that supports Wake-On-LAN. Most modern network cards support this feature, but it is recommended to verify this in the technical specifications of the card or motherboard. In addition, an ATX power supply is required, which allows the network card to receive power even when the computer is turned off. It is also important to ensure that there is an internal connection between the network card and the power supply, as this connection is essential for transferring the required voltage.
What Software Settings are Required?
Beyond the hardware requirements, you must enable Wake-On-LAN in the operating system and the computer's BIOS/UEFI. Start with the BIOS settings: enable Power Management and enable Wake-On-LAN or WOL. You will often also need to set "Wake Up by PCI-E Device" to allow the network card to wake up the system.
Then, go to the operating system settings (for example, Windows). Go to the network card properties and ask the system to "Allow this device to wake the computer." It is also recommended to check the option "Only allow a magic packet to wake the computer" to prevent unwanted activation. Make sure that the "Wake on Magic Packet" option is enabled in the advanced settings of the network card.
How to Configure the Router for Wake-On-LAN?
Router settings are especially critical if you plan to wake up pc on lan outside the home network. You must perform Port Forwarding for port 9 (UDP) to the internal IP address of the computer you want to wake up. In addition, you may need to create an appropriate Firewall rule in the router to allow Magic Packet traffic to pass. Note that in some cases, you may need to configure a static IP address for the computer or use the ARP Binding setting in the router to ensure that the Magic Packet reaches its destination even when the computer is turned off. Adhering to all these settings will ensure a smooth and efficient user experience.
What are the Advantages and Disadvantages of Using Wake-On-LAN?
Like any technology, Wake-On-LAN has notable advantages alongside certain limitations. Understanding them will allow you to make the most of the feature and manage expectations accordingly.
What Advantages Does Wake-On-LAN Offer?
One of the main advantages of Wake-On-LAN is energy saving. Instead of leaving computers running constantly, you can turn them off completely and turn them on only when needed. This not only reduces your power consumption significantly, but also contributes to reducing carbon emissions. PowerPlug was founded in 2009 to help organizations dramatically reduce their electricity bills, and technologies like Wake-On-LAN are an integral part of these solutions. Our customers include leading hospitals and medical companies, academic institutions, municipalities, government agencies, cellular operators and IT companies, all of whom benefit from the advantages of smart energy management.
Another advantage is extraordinary convenience. You can turn on a computer from anywhere in the world, whether you are at home, in the office, or on a business trip. This is an ideal solution for remote access. For network administrators, Wake-On-LAN enables more efficient management of remote computers, the ability to perform updates, installations, and maintenance at night or outside of working hours. Finally, it enables automatic backups: backup software can automatically turn on computers, perform backups, and turn them off again, without requiring manual intervention.
What are the Limitations and Disadvantages of Wake-On-LAN?
Besides the advantages, there are also limitations. Wake-On-LAN depends on the network, meaning it requires a stable wired network connection. The settings are relatively complex and require some technical knowledge, as several components must be configured – BIOS, operating system, and router. Hardware compatibility is not guaranteed; not all network cards or motherboards support this feature. And finally, there are security considerations: if not configured correctly, Wake-On-LAN may pose a security risk, as it allows the computer to be turned on without direct authentication. Therefore, it is important to adhere to appropriate security settings.
What Tools and Software Can Be Used to Send Magic Packets?
Once you understand the principles and settings of Wake-On-LAN, the next step is to know what tools you can use to send the coveted "Magic Packet" that will wake up your computer. There are a wide variety of software and applications available, adapted to different operating systems.
What Software is Available for Windows?
For Windows users, there are several convenient options. Software such as Wake-On-LAN Scanner and WOL Magic Packet Sender offer an intuitive user interface that allows you to enter the MAC address of the computer and turn it on easily. Popular remote control platforms like TeamViewer have also integrated Wake-On-LAN capabilities, allowing you to wake up a computer before connecting remotely.
What Applications Exist for Mobile Devices?
If you prefer to control your computer from your smartphone or tablet, you can find a variety of dedicated applications for Android and iOS. Applications such as Wake On Lan and Mocha WOL are common solutions that allow you to send the activation packet from anywhere, as long as you have an internet connection. Many other applications, such as Net Scan, also offer similar capabilities and even additional network management functionality.
What About Tools for Linux?
Linux users are not left out and can use command-line tools. The wakeonlan command is a common and easy-to-use tool that allows you to send the Magic Packet directly from the terminal. Another tool is etherwake, which exists in the wol package. These tools provide great flexibility for advanced users and automation.
How to Troubleshoot Common Problems?
If the computer does not wake up, here are some troubleshooting steps: Verify hardware support, check BIOS settings, reconnect cables, and ensure correct network card settings. If the problem is network-related, check router settings, port opening, firewall settings, and make sure the MAC address is correct.
